Schüco FWS 35 PD.SI - Panorama Design facade with high thermal insulation
logo
feedback
Schüco FWS 35 PD.SI

This is a Panorama Design facade of a new generation with stunning thermal insulation properties providing a perfect solution for all-glass corners which do not have profiles.

The Schuco FWS 35 PD. SI is a facade system which allows for maximum transparency, system-integrated solutions without vertical mullion profiles allowing for the first-class visual appearance and an ideal perspective view. The system is certified for use in passive houses and meets all the requirements for commercial and high-end residential buildings.

The system also allows for a wide range of accessories with a high degree of durability and reliability, for example, Schuco sun shading solutions or burglar resistance systems.

The seamless integration in the overall building envelope is provided by the combination of several Schuco Panorama Design systems.

Specifications
Uf value of frame (≥): 0.88 W/(m²·K)
Wind load resistance: Class C2 / B2
Watertightness: RE 1200
Air permeability: AE
Max. vent weight: 400 kg
Min.-max. glass/panel thickness: 22...50 mm
Burglar resistance: Up to RC3
Max. sound reduction index Rwp: 51 dB(A)
